Detail Information

Type:	Powder Coating Oven	Video Outgoing-inspection:	Provided
Marketing Type:	Ordinary Product	Core Components:	Motor
Warranty:	1 Year	After-sales Service Provided:	Engineers Available To Service Machinery Overseas, Free Spare Parts, Video Technical Support, Online Support
Fan:	High Temperature Fan	Control System:	Process Setting System:could Set Baking Temperature Etc
Heat Up Time:	30~40min	Local Service Location:	Egypt
Port:	QingDao
Highlight:	Powder Curing Coating Baking Oven , Baking Powder Coating Oven , Curing Powder Coating Oven

Product Description

When Will You Need Our Powder Curing Oven?

Your work piece need to be the metal parts, and you want your work piece could corrosion resistant, rust resistant, sun proof.
You will spray powder on the surface, then curing under the temperature 180~250 Celsius（356~482 Fahrenheit）. Your work piece maybe the doors, fence, aluminium, street poles, transformer, wheels, shopping cart, textile machinery, electric control box, motor parts, and so on, just
like the pictures below.

We will supply not only the powder curing oven, but also the powder coating booth, or the totally automatic powder coating line if you have large production.

Several Models of Our Oven

Show you some size of our powder curing ovens, so you can know more about us. And we will make the
customized design according the work piece details you gave to us.

Colin-160

- Available dimensions: 875x845x1600mm
(L*W*H);
- Exterior dimensions: 1115x 1165x 2040mm (L*W*H);
- Rock wool panel: Hand-made 100mm rock wool panel
- Heating tube: 2kw*3 sets
- Heat up time: 15-30 min. (180°C)
- Temperature max. 250° C
- Warranty: 12 months
- Function: Curing the alloy wheels, one time can curing 4 sets.

Colin-330

Available dimensions:
3125 * 3050 * 2500 mm ( L*W*H );
- Exterior dimensions:
3550 * 3650 * 3000 mm ( L*W*H );
Wall panel: 150 mm rock wool panel, with the rock wool density 100 kg/cubic meter.
- Power supply: FS 10 Gas burner;
- 1 unit 1 unit 4 kw
- Heat up time: 15-30 min. (180°C)
- Temperature max. 250° C
- Warranty: 12 months

Colin-600

- Available dimensions:
7500 * 2400 * 2875 mm ( L*W*H );
- Exterior dimensions:
7800 * 4300 * 3700 mm ( L*W*H );
Wall panel: 150 mm rock wool panel, with the rock wool density 100 kg/cubic meter.
- Power supply: FS 20 Gas burner;
- Circulation fan: 1 unit 5.5 KW
- Temperature max. 250° C
- Warranty: 12 months

Colin-1100

Size:10350*2800*2710 mm(L*W*H) ;
- Circulation fan: 1 unit 7.5 kw fan
- Automatic Chain type: QXG-250,speed: 0.7 m/min.
- Driving motor: 2.2 kw
- Curing time: 20 min under the speed 0.7 m/min.
You can adjust by yourself.
- Temperature max. 250° C
- Warranty: 12 months

Product Description

Our oven can help you curing the powder after you finish the powder coating work for your metal parts.

The wall of the oven we use the 150mm thickness rock wool panel usually, and the heating system you can choose natural gas, LPG, diesel or electric.

We suggest the natural gas and LPG heating system first, as the using cost for the natural gas and LPG is not so much, also the 2 heating system is much more clean than diesel. And usually we don't suggest the electric heating, as it will use a lot of power in the afterdays.

We provide free designing service,according to your actual condition, we will draw a suitable size oven for you. So hope you could help us to know more details about your work piece.

The blue color powder coating booth and oven project was designed for our Australia customer who supply the powder coating service to all kinds of metal parts. And this equipment asked for heavy bearing for the rail, and bigger production, so we designed for the top sliding trolley type.

Rock Wool Panel

We use rock wool panel to build the oven. The thickness is 150 mm, and the density for the rock wool is 100 kg/ cubic meter. And we use
75 mm thick panel for the ground

Heating Unit

The heating way can be natural gas, diesel or
the electric. And the heating unit can but beside the oven, or on the top of the oven to save space

Control Box

You can set the curing temperature, curing time
for the oven. And there is emergency stop, high temperature alarm on the control box

The Air Duct Outside Oven

The air duct outside the oven is hand made, we welding the clod plate and put the rock wool inside.

Air Circulation System

The air duct inside the oven will looks like this.

The Column for the Oven

We will choose the right model column according the size of the oven and the weight of your work piece.

Powder Curing Oven Details:
11200Outside dimensions:	11200 3400 3130mm ( LWH ) Or customized
Inside dimensions:	11000 * 2800 * 2805mm ( LWH ) Or customized
Material of oven:	150mm thickness rock wool panel
Front door size:	31002800mm (WH)
Heating System	Italy Riello brand burner for 440,000kcal/h; 1 unit 1 unit 11 kw high temperature resisting fan
Heat-up time:	20-30 min. (180°C) - Temperature stability : < ± 1-3°C - Temperature max. 250° C
Warranty:	12 months
Voltage/Frequency:	Voltage/Frequency:
Powder Coating Booth details:
Outside dimensions:	1120035003020mm ( LWH ) Or customized
Inside dimensions:	1110034202900mm ( LWH ) Or customized
Material of powder coating booth	2.0mm powder coated cold rolles steel sheet
Front door size	25002750mm (WH)
Exhaust fan	2 pieces 7.5kw fan

Detailed Image

Our Company

Colin Coating Equipment Co,.Ltd is a professional powder coating equipment manufacturer in China for more than 9 years. We can design and produce the manual powder coating equipment and also the automatic powder coating equipment. Now we have more than 150 employees, and 3 work shop, total more than 10,000 square meter. We have 2 laser cutting machine, 1 plasma cutting machine, 2 bending machine, 1 pressure cutting machine and 8 welding platform.

Our Advantages

1.We have more than 9 years' experience in manufacturing powder coating products, and we exported to more than 40 countries.

2.Like the pictures above, we will do the pre-installation before you do the balance payment. In this way, it's more safe to you toarrange the payment. And the pre-installation process can also help you know the installation steps of the equipment, you can do the installation very easily when the equiplment arrive.
3.We have professional saling team and engingeers team to do very good after-sales service.
4.We have our own factory, we can make the customized design just according your real situation.
5.There are a lot of manual powder coating projects and automatic powder coating projects we did around our city, if you would
like to come for visiting, then we will show you our real projects to you.
6.As for the installation, if you don't want to do by yourself, even we already make the pre-installation. Then you can choose our
engineers to go to your city and guide your people to do the installation. If you don't want our engineer to go.

Engineer Installation

Manual Powder Coting Project in Australia

Automatic Powder Coating Line in Kazakhstan

Customers' Visiting Photos

We are in Yantai City, Shandong Province, the North of China.

The airport name is Penglai Internation Airport, or you can just search our city name Yantai, as we only have one airport.

We also have 2 high speed railway station, Yantai or Yantai South.

Welcome for your visiting, as the visiting is the best way to know more details of us, also you will see more projects by the visiting.

Russia Customer

France Customer

Kuweit Customer

UAE & Tanzania Customer

Mozambique Customer

Australia Customer

Packing & Loading

The goods will be packed by plastic foam and have cushion effect, with wire fixation.
And we will package the heavy parts together so it can easily moved by the forklift, like the rock wool panel.

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory and can do the exporting work by ourselves.

Q: How long is your delivery time?

A: About 45 workdays after received the deposit.

Q: What is your terms of payment ?

A: T/T, Irrevcoable L/C. 30% T/T in advance, 70% balance before shippment.

Q: Can engineers service overseas?

A: Yes, total no problem.

Q: What about the guarantee period?

A:You will have 12 months guarantee time for the powder coating booth, if the parts broken as our mistake, we will send you by DHL.

But as we do the pre install before the laoding, so this situation won't very easy to happen we believe.

After one year, if you still have any help about the equipment, please feel free to contact us at any time, as we will supply you lifelong service.

Tag:

Place of Origin:	Shandong, China
Brand Name:	Colin
Certification:	CE/ISO9001

Price:	Negotiate
Packaging Details:	Packed in Parts and load in containers or according to the customers' requests
Supply Ability:	30 Set/Sets per Month
