Detail Information

Type:	Powder Coating Oven	Substrate:	Steel, Steel, Rock Wool Heat-insulation
Condition:	New	Machine Type:	Baking Oven, Plc Controller Programmable Logic Controller, Conveying Equipment, Drying Oven, Curing Oven, Coating Equipment
Video Outgoing-inspection:	Provided	Machinery Test Report:	Provided
Marketing Type:	New Product 2022	Warranty Of Core Components:	1 Year
Core Components:	PLC, Motor	Coating:	Powder Coating
Voltage:	380V/220V	Power:	5.5Kw
Dimension(LWH):	6000x3000x2800mm	Warranty:	12 Months
Key Selling Points:	Easy To Operate	Applicable Industries:	Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Farms, Home Use, Retail, Construction Works
Showroom Location:	Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, Mexico, Russia, Spain, Thailand, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Algeria, Sri Lanka,	Weight (KG):	6000
After-sales Service Provided:	Engineers Available To Service Machinery Overseas	Color:	Customized Color
Model:	As Required	Heating Energy:	LPG/Liquefied Natural Gas/Diesel/Electric/Coal
Heating System:	Riello Diesel Burner/gas Burner/electric Heating Tube	Product Name:	Powder Coating Baking Oven
Size:	Customized	Feacture:	Heating Up Quickly
Delivery Time:	Quickly Within 30days	Port:	Qingdao
Highlight:	Compact Batch Powder Coating Oven , compact batch powder coating oven

Product Description

O-269 hot air circulation compact batch oven, industrial oven, powder coating oven

Exemplary Examples of powder coating oven

No.	Item	Description
1	Demension	External size: 6300mm(L)×3300mm(W)×3100mm(H);or as requirement Internal size: 6000mm(L)×3000mm(W)×2800mm(H)
2	Wall Panel	150mm thick heating-resisting rock wool steel board, sandwich: Outside panel is 0.5mm thick colorful steel skin boards, and Inside panel is 0.5mm thick galvanized sheet plate.
3	Entrance Door	W3000mm×H2800mm or as requirement; Handiwork metal plate 2-door; Be equipped doorknob, etc.
4	Ground Rail	High quality steel rack;
5	Circulation Fan	1 unit 4kw high temperature fan. Air flow capacity: 9000m³/h; Fan and burner box inner is 1.2mm thick stainless steel; Out is also 150mm thick rock wool panel to keep heat.
6	Heating System	1 set of Riello FS34 natural gas(LPG,diesel) burner, 340000KCal/h Max temp:220℃, heating time: 20-25min(180-220℃)
7	Motor Power	380V AC/3Ph/50Hz; or as requirement;
8	Electrical Control System	Baking, Indicator; Pre-set baking time; Power On/Off Control, Indicator; Emergency Stop
9	Working Temp.	200℃

Customization of powder coating oven

For customized design upon your request , please kindly let us know the detailed info :

1. Workpieces Max weight and Max size (length ,width and high) and picture.

2. The material of the workpiece.

3. The heating power: Liquefied Petroleum Gas, Liquefied natural gas, Diesel, Electric, Coal or

Biomass particles.

4. The local electricity conditions(V/PHASE/HZ)

FAQ

1.Installation?

Deliver with detailed specification of installation and operation

2.Payment terms?

T/T,30% for deposit and the balance 70% before loading into container.

3.About design?

Please let me know the details,for example:the size of the workpieces,meterial description,

output capacity,the size of the workshop,change colors situation,electricity types and other

Place of Origin:	Shandong, China
Brand Name:	ABD

Price:	Negotiate
Packaging Details:	standard package ,or as clients's want.(powder coating oven)
Supply Ability:	20 Set/Sets per Month
