Detail Information

Video Outgoing-inspection:	Provided	Machinery Test Report:	Provided
Marketing Type:	Ordinary Product	Warranty Of Core Components:	1 Year
Core Components:	PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump	Coating:	Powder Coating
Power:	10-200KW	Dimension(LWH):	According Customer Requirements
Warranty:	1 Year	Key Selling Points:	Good Quality
Applicable Industries:	Hotels, Manufacturing Plant	Showroom Location:	Egypt, Canada, Turkey, United Kingdom, United States, France, Brazil, UAE, Ukraine
Weight (KG):	100000	After-sales Service Provided:	Engineers Available To Service Machinery Overseas
Heating System Of Powder Coating Oven:	Gas/electric/LPG/Diesel Etc	Temperature Of Powder Coating Oven:	Generally Between 180-220℃, Can Be Set According To Customer Needs
Wall Panel:	Rock Wool Steel Board,150 Mm Thick,anti-flame And Heat-insulation	Control System:	Process Setting System:could Set Baking Temperature Etc
Total Powder:	Various According To Different Heating Systems	Metal Car Rims Powder Coating Oven:	Iron Car Rims Powder Coating Oven
Iron Profile Powder Curing Oven:	Aluminium Powder Heating Oven	Iron Frame Powder Melt Oven:	Metal Fence Powder Coating Curing Oven
Highlight:	Powder Coating Oven Gas Stoves , Industrial Gas Stoves , Industrial Gas Stoves Oven

Product Description

Industrial Gas Stoves And Powder Coating Oven

Product Description

Inside Size(mm)	6000x3000x2800mm (LXWXH)
Outside size(mm)	6300x3300x3500mm (LXWXH)
Wall panel	Rock wool steel board,150 mm thick,
Wall panel	anti-flame and heat-insulation
Pass type doors	2 sets ,30002800m(WH)
Fan	1 set 5.5 kw high-temperatute fan,air flow capacity:9000m³/h
Heating system	1set of Riello FS34 natural gas burner,340000KCal/h
	stainless steel heat exchanger
	max temp:250 ℃, heating time: 20-25 min (180-250℃).
	Fan and burner box inner is 2 mm thick galvanized steel,interlayer 150mm thick rock wool,out is 1.2mm thick galvanized steel to keep heat
Control system	Temperature alarm(With inductor in the oven) ,stop button,process setting system:could set baking time and temperature,when baking time arrive,stop automaticly
Total power	5.5kw

Place of Origin:	Shandong, China
Brand Name:	ABD

Price:	Negotiate
Packaging Details:	industrial gas stoves and ovens package: load in container or according to customer's needs
Supply Ability:	30 Set/Sets per Month industrial gas stoves and ovens

Industrial Gas Stoves And Powder Coating Oven

Powder Coating Oven Gas Stoves
