Modern design low price powder coating line

Basic Information
Place of Origin: Guangdong, China, Yantai
Brand Name: ABD
Certification: CE
Price: Negotiate
Packaging Details: powder coating oven infrared heater package: load in container or according to customer's needs
Payment Terms: L/C, T/T
Supply Ability: 30 Set/Sets per Month powder coating oven infrared heater
Detail Information
Type: Coating Production Line Substrate: Steel
Condition: New Machine Type: 2021 New, Coating Oven
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2021 Warranty Of Core Components: 1 Year
Core Components: PLC, Motor Coating: Powder Coating
Voltage: As Customers Local Voltage Power: Multi Power
Warranty: 2 Years Key Selling Points: Long Service Life
Showroom Location: None Weight (KG): 500
After-sales Service Provided: Engineers Available To Service Machinery Overseas Temperature: Generally Between 180-220℃, Can Be Set According To Customer Needs
Wall Panel: Rock Wool Steel Board,150 Mm Thick,anti-flame And Heat-insulation Control System: Process Setting System:could Set Baking Temperature Etc
Oven Type: One Door, Two Doors(pass-type) And "bridge" Type Coating Color: Customers Demand
Advantage: Environmental-protection
Highlight:

Modern design powder coating line

,

Low price powder coating line


Product Description

Modern design low price powder coating oven infrared heater

Why choose us?
  1.With more than 10-year experience for painting machine,
2.Export more than 100 places around world, Australia,Africa,Asian,America,Europe etc.
3.Best post-sell service, offer oversea service for you to install for use.
4 Provide professional person to communicate with you before the order.
Top design.
1. Provide strict quality check for each part, each process before export.   2. Provide optimum system solution based on each client’s specific requirement and local location’s weather condition.  3. Provide complete post-sale service, including installation, technical guide and training.

Modern design low price powder coating line 0

PRODUCT SPECIFICATIONS
No
Item
1. Inside Size(mm)
4500x3000x3000mm (LXWXH)
2. Outside size(mm)
4800x3300x3300mm (LXWXH)
3. Wall panel
Rock wool steel board,150 mm thick,
anti-flame and heat-insulation
4. Front door size
3000*3000mm(W*H)
5. Fan
1 set 3kw high-temperatute fan,air flow capacity:3000m3/h
6. Heating system
1set of Riello G20 diesel burner
Stainless steel heat exchanger
Max temp:220 ℃, heating time: 20-25 min (180-220℃).
Fan and burner box inner is 2 mm thick galvanized steel,interlayer 150mm thick rock wool,out is 1.2mm thick galvanized steel to
keep heat
7. Control system
 Temperature alarm(With inductor in the oven) ,stop button,process setting system:could set baking time and temperature,when
baking time arrive,stop automaticly
8. Total power
3Kw
PRODUCT CONFIGURATION
Modern design low price powder coating line 1
